Industry-proven low loss dielectric test solution
- Ideal for evaluating low loss dielectric materials with tan δ 0.01 or less.
- Easy operation: simply inserting a rod-shaped sample into the insertion hole
- Efficient and reliable measurement with permittivity measurement software
- Robust hardware provides reproducible measurements over the years
- Powder measurement (option)
The TM resonator is a highly reliable solution that has been used extensively by many companies and research institutions for over a quarter of a century since our company began selling for the first time in Japan. With the extremely high Q value (over 10,000, typical) of the resonator itself, it is possible to accurately evaluate low loss materials with tan δ of 0.01 or less. Furthermore, since the measurement procedure is simple, you can efficiently measure materials with high repeatability. You can simply insert the rod-shaped sample into the sample insertion hole in the upper part of the resonator, and just click "measure". The measurement software guides you through the measurement with step-by-step explanation, with which you can obtain the correct measurement result from the beginning.
Need help selecting the right system?
Tell us your frequency range and sample requirements, and we will recommend a suitable configuration.
Watch and Learn: TM Resonator
Simple to Use, Powerful in Performance — See It in Action!
Measurement Examples
Sample size
Recommended sample size [mm]
| Cross section | Length | |
|---|---|---|
| square | 1.5x1.5 or less | 80mm or more |
| circle | Φ2.6 or less | 80mm or more |
*For measurements at 10 GHz, a length of 60 mm is acceptable.
Example System Configuration
- Keysight Streamline USB Vector Network Analyzer P5003B (14 GHz)
- TM resonator 1 GHz : CP-001
- Software for split cylinder : CP-MA
- Cables 2.92mm
- Windows 10 PC
Products
Standard
| Product No. | Product Name |
|---|---|
| CP-001 | TM resonator 1GHz |
| CP-002 | TM resonator 2GHz |
| CP-245 | TM resonator 2.45GHz |
| CP-003 | TM resonator 3GHz |
| CP-005 | TM resonator 5GHz |
| CP-580 | TM resonator 5.8GHz |
| CP-010 | TM resonator 10GHz |
Standard + Powder/Liquid measurement
| Product No. | Product Name |
|---|---|
| CP-001-PW | TM resonator 1GHz for powder & liquid |
| CP-002-PW | TM resonator 2GHz for powder & liquid |
| CP-245-PW | TM resonator 2.45GHz for powder & liquid |
| CP-003-PW | TM resonator 3GHz for powder & liquid |
| CP-005-PW | TM resonator 5GHz for powder & liquid |
| CP-580-PW | TM resonator 5.8GHz for powder & liquid |
| CP-010-PW | TM resonator 10GHz for powder & liquid |
Even with a TM resonator designed for powder/liquid measurement, rod-shaped materials can still be measured (upward compatible).
A standard TM resonator can be upgraded later for powder/liquid measurement.
When measuring powder samples, we recommend using the software with the powder measurement option.
Applicable standards
- JIS C2565
- IEC 62810
